3/4,3/8 Inch Preset Torque Wrench,TGK Series
-
Brand：Axion
Accuracy：±3%
Model Number：TGK
Torque range(Nm)：1-2000Nm
Driver(inch)：3/8，1/2，3/4 ,1/4 , 1
L/W/H(mm)：210-1795/28-68/25-62
Weight(kg)：0.38-15.02
Place of Origin: China
Customized: OEM,ODM
Minimum Order: 1Piece
SKU:AXT-116-00450
- 3/4,1/2 Inch Preset Torque Wrench,TG Series 1/2,3/4 Inch Preset Torque Wrench,DP Series 1/2,3/4 Inch Preset Torque Wrench,DA Series 4-10000 Nm Preset Torque Wrench,AC Series
Description
Product Line: Industrial Tools
Customizable with special requirement
Accuracy: Level 3 with precise results and minimal deviations.
Error range: The error range of within 3% ensures
accurate and reliable measurements,
making it suitable for a wide range of applications.
Beautiful appearance, showcasing elegance and style.
High torque accuracy for efficient performance.
Good stability, maintaining steady operation.
Equipped with a differential device for enhanced stability.
Dimensions
| TGK type preset torque wrench | ||||||||
| Model Number | Torque range | Driver/inch | Length/mm | Width/mm | Width/mm|Height/mm | Weight/kg | Fine Scale/N.m | Ratchet Teeth |
| TGK 19501 | 1-5 | 1/4" | 210 | 28 | 25 | 0.38 | 0.1 | 22 |
| TGK 19502 | 2-10 | 1/4" | 210 | 28 | 25 | 0.38 | 0.2 | 22 |
| TGK 19503 | 5-25 | 3/8" | 370 | 33 | 30.5 | 0.54 | 0.25 | 22 |
| TGK 19504 | 20-100 | 3/8" | 370 | 33 | 30.5 | 0.54 | 0.25 | 22 |
| TGK 19505 | 60-300 | 1/2" | 640 | 47 | 48 | 2.35 | 2 | 19 |
| TGK 19506 | 100-500 | 3/4" | 690 | 47 | 48 | 2.35 | 2 | 19 |
| TGK 19507 | 250-750 | 3/4" | 835 | 56 | 53 | 4.07 | 2.5 | 18 |
| TGK 19508* | 200-1000 | 3/4" | 835+535（1237） | 56 | 53 | 5.60+1.86 | 4 | 18 |
| TGK 19509* | 750-2000 | 1" | 1110+735（1795） | 68 | 62 | 9.50+5.52 | 5 | 15 |
FAQs
How do you use a preset torque wrench?
To use a preset torque wrench, first determine the correct torque value and adjust
the wrench to the desired value by turning the handle or knob until the scale aligns
with the required torque setting. Then, attach the appropriate socket or bit to the
wrench and tighten the fastener until you hear or feel a click, indicating that the
pre-set torque has been reached. If multiple fasteners need to be tightened to the
same torque value, ensure that the wrench is reset to the appropriate setting before each use.
What is a preset type torque wrench?
A preset type torque wrench is a specialized tool designed to apply a specific amount of torque to a fastener.
Unlike adjustable torque wrenches that allow users to set different torque values, a preset torque
wrench comes with a fixed torque setting determined by the manufacturer. These wrenches are commonly
used in assembly lines or situations where consistent and precise torque application is required.
